Your current location: ProductsOther ValvesBrass Flange Gate Valve

Z45W-16 Brass Flange Gate Valve

Product overview

Product model: Z45W-16
Nominal diameter: DN125~200mm
Nominal pressure: 1.6MPa
Working medium: water, non-corrosive liquid, saturated steam (≤ 0.6Mpa)
Operating temperature: -20℃≤ T ≤150℃

Z45W-16 Brass Flange Gate Valve product details

Z45W-16 Brass Flange Gate Valve main dimensions


DN 125 150 200
A 180 203 250
B 125 150 200
C 382 433.5 553.5
D 237 237 320
D1 250 285 340
¢D 18 22 22
n 8 8 8


Reminder:

All text, data and pictures in this article are for reference only.To see more details of the Z45W-16 Brass Flange Gate Valve performance parameters, structural dimension parameters, pricing, etc., or to request high quality printing samples, please Contact us.
